The Flex II Paint Booth was designed for automotive shops that paint more than 90 cars per month, including armored vehicles. Focused on premium finishes and maximum efficiency, this booth raises the bar by reducing rework and optimizing production processes, making the business more competitive and profitable.
Your airflow system Down Draft A positive pressure system directs filtered air from the ceiling to floor filters, minimizing contamination and protecting the operator and the environment from polluting particles. Unlike other models, the Flex II includes its own base for the outlet filtration system, eliminating the need for additional civil works.
The booth also features adjustable temperature control, speeding up drying in cold conditions without compromising finish quality. This ensures uniform paint finishes even in adverse weather conditions, ensuring a high standard of excellence year-round.
Benefits
High Performance for Large Volumes – Ideal for operations that require painting more than 90 cars/month, including armored vehicles.
Contaminant-Free Environment - Flow Down Draft positive pressure, reducing overspray and rework.
Own Base Included – Eliminates the need for civil works, simplifying installation.
Adjustable Temperature Control – Allows for customized climate control, accelerating drying and maintaining quality.
Optimized Maintenance – Quick filter change system and complete control panel for easy management.
Technical Characteristics
- Based on
- Structure with thermoacoustic insulation in 50mm PIR panels and raised floor with grids for easy removal of filters.
- Airflow system DOwn Draft, that is, with ceiling and floor filtration and an integrated base for outlet filtration.
- Adjustable temperature control to optimize the drying process in different weather conditions.
- Lighting with 40 LED lamps at 45º, providing 750 lux without shadow areas.
- High-performance equipment with Italian burner, stainless steel heat exchanger and pneumatic dumper.
- Emergency side access, option with base (no civil works) and filter kit for immediate use.
Available Models and Dimensions
Total width*: 4,000mm / Useful: 3,900mm
Total depth*: 9,000mm / Useful: 6,900mm
Total height: 3,400mm / Useful: 2,650mm
*1,200mm must be added to the total external measurement (side or rear) depending on the location of the module.
